Integrated dome controls
On-head buttons let clinicians adjust intensity instantly - no separate panel and no fumbling at the sterile field edge.
Examination Lights
Luminox Series
Compact examination light - surgical-grade clarity for procedure rooms, clinics, and everyday clinical work.
Engineered for the everyday - every examination, every minor procedure, every bedside intervention illuminated with surgical-grade clarity.
Luminox Series (Luminox 300) condenses the optical performance hospitals expect from a full operating-theatre light into a compact, energy-efficient unit for examination and procedure rooms.
Purpose-built
What Luminox 300 delivers
High-intensity illumination, manoeuvrability, dome controls, and daylight-true colour in a compact form factor suited to examination and procedure rooms.
High-intensity illumination
100,000 lux central illumination at 1 m with uniform, shadow-managed output across the working field.
Multi-axis manoeuvrability
Spring-balanced arm lifts, tilts, pivots, and rotates - locking firmly at any chosen position.
Integrated dome controls
On-head buttons for instant intensity adjustment without a separate control panel.
Cool, energy-efficient LEDs
Low-power LED engine under 25 W with minimal heat emission for patient and clinician comfort.
Compact, streamlined design
300 mm head with a modern aerodynamic shape that reduces visual obstruction in tight clinical spaces.
Daylight-true colour
6500 K ± 500 K CCT with CRI > 90 for accurate tissue and skin assessment.
60,000+ hour LED life
Long-life LED service span built for high-utilisation clinics and wards.
Smooth, easy-clean housing
Open-type rounded body with no sharp corners - every surface wipes down hygienically.
High depth of illumination
Powerful, uniform light with clear visibility deep into the working field.
Globally certified
ISO 13485 manufacturing with CE marking and CDSCO compliance for international tenders.
Performance and clarity
Surgical-grade clarity for examination rooms
Luminox 300 brings surgical-grade optical performance into examination and procedure rooms without the footprint of a full OT light.
Fixed focus, daylight CCT, and on-head intensity control support detailed assessments and minor procedures with readable tissue colour.
Key features
Designed for everyday clinical examination
Fixed-focus Luminox 300 optics with on-dome intensity control and a shared mount matrix for mobile or ceiling single-dome installs.
Aluminium plate with LED PCB
Mounted on an ABS base for efficient thermal management and stable output.
Sterilisable handle
Aseptic control from the sterile field during procedures.
Fixed daylight CCT
6500 K ± 500 K colour temperature with CRI > 90 for tissue visualization.
Ergonomic design
Shaped for better grip and confident positioning.
Keypad control panel
Intuitive on-dome interface for intensity control across 0–100% dimming.
Fixed focus optics
Stable 250 mm field at 1 m without variable focus modes to manage.
In the field
Compact light for clinics and procedure rooms
From outpatient assessments to minor procedures, Luminox 300 delivers consistent high-quality illumination where examination rooms and procedure bays need surgical-grade clarity in a compact footprint.
In detail
Smooth, easy-clean housing
Open-type rounded body with no sharp corners or crevices - every surface wipes down hygienically between patients.
Globally certified manufacturing
Manufactured under ISO 13485 with CE marking and CDSCO compliance - qualified for international tenders.
Luminox 300 compact head
300 mm fixed-focus head with 100,000 lux at 1 m, 6500 K ± 500 K CCT, and CRI > 90 for examination and procedure rooms.
Specifications
| Parameter | Luminox 300 |
|---|---|
| Max. Central illumination at 1 m | 100,000 lux |
| Light field diameter at 1 m (d10) | 250 mm ± 10% |
| Light head diameter | 300 mm |
| Depth of illumination at 20% (L1+L2) | 1300 mm |
| Depth of illumination at 60% (L1+L2) | 800 mm |
| Correlated Color Temperature (CCT) | 6500 K ± 500 K |
| Color Rendering Index (CRI) | > 90 |
| Power consumption | < 25 W |
| Focus Mode | Fixed |
| Dimming Range | 0 – 100 % |
| No. of LEDs | 12 |
| LED Service Life | 60,000 hours |
| Supply Voltage | 230 V ±10%, 50 Hz ±5% |
| Power Supply Unit | 24 V DC ±10%, 4.2 A max |
| Operating Temperature | 5°C - 40°C |
| Humidity | 10% - 90% |
Frequently asked questions
- What optical performance does Luminox 300 provide?
Luminox 300 delivers 100,000 lux at 1 m from a 300 mm fixed-focus head with 6500 K ± 500 K CCT, CRI > 90, a 250 mm field (d10), and under 25 W power consumption.
Source: Luminox Series product specifications- Which mounts are available for examination use?
Mobile castor and single ceiling mounts are specified for examination and procedure rooms. Wall mounts can be adapted through custom development.
Source: Luminox Series configurations- Are Luminox lights IEC compliant?
Yes. All values conform to IEC 60601-2-41 and are subject to a general industrial tolerance of ± 5%.
Source: Luminox Series product specifications- How does Luminox Series relate to Luminox Brighto?
Luminox Series (Luminox 300) is a compact surgical-grade examination and procedure light. Luminox Brighto and Brighto Mini are dedicated examination spotlights with different lux ranges and smaller light fields for outpatient and ward use.
Source: EPMD examination lights catalogue
